17-key RGB remote control solution - open the night colorful mode for the bedroom



I have a client who makes lamps and received an order for a smart home system: to make an LED lamp that can be controlled by an RGB remote control. The customer came to us to help develop an RGB remote control solution, and requested to realize multi-color control conversion, which can remotely switch LED lights.



       We have been committed to the R&D and manufacturing of wireless remote control and smart home supporting products for more than ten years. For the solution design of this RGB remote control, engineers with 20 years of design experience are very familiar with it. After a short communication, the engineer listed the customer's required functions:



       1. Using RF radio frequency for wireless remote control, the signal transmission is strong, and it is not easy to be interfered by radio. The remote control of conventional lamps or light strips is infrared, and the distance of infrared remote control is limited. The remote control will fail when the controller is blocked. The use of RF radio frequency technology solves this problem;

       2. Realize fast and smooth color switching through the buttons on the remote control;

       3. Adjustable speed and conversion mode.

       The biggest feature of this remote control is that customers are very satisfied with this design, so the 17-key RGB remote control came into being: it uses a single-chip microcomputer chip for self-programming, custom encoding format, not easy to decode, and has higher security. Interference from other devices. It can be used in lighting control, smart home remote control and other fields. The finished 17-key functions are as follows:



      1. On key: Press the switch lightly to start the lamp; press the switch lightly again to turn off the lamp (with memory function, which can save the last working state);

       2. MODE+ key: switch from static mode to dynamic mode, and can switch dynamic mode;

       3. SPEED-key Dynamic speed reduction button, every time the switch is pressed, the dynamic speed will be reduced by one gear;

       4. DEMO button: press this button, the lamp will switch to demo mode: in demo mode, it will show 9 dynamic modes in turn, and each mode will be repeated 3 times;

       5. SPEED+ key: Press the key SPEED+ --- the dynamic speed acceleration key, each time the switch is pressed, the dynamic speed will increase by one gear;

       6. COLOR+ key: COLOR key, you can switch the lamps from dynamic to static mode; COLOR key, the lamps can be switched statically in positive order according to different colors;

       7. MODE-key: MODE-key - switch from static mode to dynamic mode, and can switch dynamic mode;

       8. BRIGHT+ key: press BRIGHT+, the brightness of the static lamp bead will gradually increase;

       9. COLOR-key: COLOR key, you can switch the lamps from dynamic to static mode; COLOR key, the lamps can be switched statically in reverse order according to different colors;

       10. White key: Press the key once to switch the light to white;

       11. BRIGHT-: Press BRIGHT-, the brightness of static lamp beads will gradually decrease;

       12. Red button: press the button light to switch to red button;

       13. Green button: Press the button light to switch to a green button;

       14. Purple key: Press the button light to switch to purple key;

       15. Yellow key: Press the button light to switch to yellow key;

       16. Blue button: Press the button light to switch to the blue button;

       17. Pink key: Press the key light to switch to pink key.

       In addition, in order to use the product reasonably and prolong the service life of the product, we have sorted out the precautions for using the RGB remote control and possible failures as follows:

       1. The battery voltage cannot exceed the working voltage;

       2. In an environment with relatively large wireless interference, the transmission distance may be reduced;

       3. Keep out of reach of children;

       4. It is forbidden to use it in a humid environment, otherwise it may cause damage to the remote control;

       5. If the controller is not controlled by the remote control, please check whether the controller is powered on;

       6. If you find that the remote control distance becomes shorter or the red indicator light on the remote control becomes dim, please replace the battery;

       7. If the bright color of the light bar does not correspond to the color of the remote control color ring, please check the wiring between the LED light and the controller. If you press the red LED to light green, and press the green LED to light red, it means that the wiring of the red light and the green light are reversed.



       The RGB remote control makes the color change of the light strips in the bedroom easier and controllable, making the bedroom more warm and dreamy at night. The customer is very satisfied with this cooperation. This solution can be used not only in bedrooms, but also in places that require energy-saving and high color rendering index lighting such as hotels, scenic area outline decoration, meeting rooms and outdoor billboard decoration.
