BF-H6 10W 2200mAh 128 Group Channels Walkie Talkie 400-520MHz 136-174MHz Dual Band Handheld Radio Walkie Talkie Civilian Interphone Intercom With Earphone
- Stock: In Stock
- Model: EB0024778
- Dimensions: 134.00mm x 62.00mm x 32.00mm
- SKU: EB0024778
General:
Frequency Range | VHF:136-174MHz UHF:400-520MHz(Dual band) |
Memory Channel | 128 Group |
Channel Spacing | 25KHz(Wide), 12.5K(Narrow) |
Operating | Voltage DC7.4V |
Frequency Stability | ±2.5ppm |
Operating Temperature | -20~+60℃ |
Antenna Impedance | 50Ω |
Transmit Current | H≤2.5A, M≤1.8A, L≤1.1A |
Modulation(Wide/Narrow) | 16KΦF3E/11KΦF3E |
Maximum deviation | ≤±5 kHz/≤±2.5 kHz (W/N) |
Stray Power | ≤7.5uW |
Adjacent Channel power | ≤-65dB/≤-60dB |
Signal-to-noise(wide/narrow) | ≥-45dB/≥-40dB |
QT/DQT Deviatio (wide/narrow) | 0.7±0.1KHz/0.4±0.1KHz |
Modulation Sensitivity | 8-12mV |
Demission | 134*62*32mm(no including the antenna) |
Weight | About 300g(include in battery and antenna) |
Receiver:
- Receiver Sensitivity ≤0.25uV(12dB SINAD)
- Audio Power 1W@10%
- Audio Distortion <10%
- Signal-to-Noise ≥45dB
- Adjacent Channel Selecitivity(wide/narrow) ≥-65dB/≥-60dB
- Intermodulation(wide/narrow ) ≥-65dB/≥-60dB
- Stray Suppression ≥-65dB
- Receive Current ≤380mA
Standard Package Content:
1 x BAOFENG BF-H6 Walkie Talkie
1 x 2200mAh Li-ion Battery Pack
1 x Charger Unit with AC Adapter
1 x Antenna
1 x Hand Strap
1 x Belt Clip
1 x Earpiece
1 x User Manual
