T.SK105A.03 Universal LCD LED TV Controller Driver Board +7 Key button+1ch 6bit 40Pins LVDS Cable+Speaker+EU Power Adapter

Based on 0 reviews. - Write a review

$28.99

Ex Tax: $28.99

Stock: In Stock
Model: EB0048632
SKU: EB0048632

Qty

Add to Cart

Buy Now Ask Question

Add to Wish List Compare this Product

Precise details:

T.RD8503.03 Firmware: Click here to open

T.V53.03 Manual: Click here to open

T.V53.03 Firmware: Click here to open

T.SK106A.03 Manual: Click here to open

T.SK106A.03 Firmware: Click here to open

New Version T.SK105A.03 Manual: Click here to open

New Version T.SK105A.03 Firmware: Click here to open

Note: Since the driver board model is updated frequently, the appearance and chip will be different, please refer to the actual received. If you mind this, please buy carefully.

Please note before buying:

1. This product is compatible with most models. Customers only need to confirm that the LCD screen is compatible with the following resolutions, without repeating the inquiry model. (Firmware burns the corresponding resolution)

2. This product needs to burn the firmware by yourself before it can be used. If you don't know how to burn the firmware, unfortunately, it is recommended not to buy. Thank you for your understanding.

3. This kit comes with a 1ch 6bit 40pins screen cable by default. If it is not compatible with your screen, please purchase a matching screen cable separately.

4. Be sure to use the correct power supply. If the current is too low/too high, it will fail to boot, or even burn out the chip and damage the motherboard.

5. Please pay attention to the choice of screen voltage 3.3V/5V/12V, and change the position of the jumper cap according to different voltages.

Only supports the resolution of:

1920x1200

1920x1080

1680x1050

1680x945

1600X1200

1600x900

1400X1050

1440x900

1366x768

1280x1024

1280x854

1280x800

1280x768

1280x720

1024x768

1024x600

800x600

Burning method: to record the screen program in the USB flash disk, USB flash disk inserted into board, plug in the keypad, electricity; About after a few seconds, press the keypad lights start alternating red and green flash, flash lights began to write programs (please do not power), light in the slow flash first, after a slow flash flash, will speed up the quick flash, long after the last until the lights stop flashing light is the program written, electricity burn with USB flash disk to complete the program.
Not only USB interface can be used to upgrade programs, but also can use to play video, basically formats are supported. You can also set a boot display pictures or LOGO

After the firmware is successfully burned, you can use the remote control to debugging: menu input 1147 to enter the factory mode for debugging

Description:

Model: T.V53.03 (Update from December 25, 2019)

Model: T.SK106A.03 (Update from September 1, 2020) (CN warehouse)

Update Model: T.SK105A.03 (Update from November, 2020) (CN warehouse) The specific model is mainly based on the received model, pay attention to burning the corresponding model firmware.

TV Format: Analog Signal

Support Language: Russian, English, Hindi, Simplified Chinese, Khmer, Vietnamese, Myanmar, French, German, Italian, Spanish.

Input Interface: PC / HDMI / TV / AV / USB multimedia playing (Note: TV signals can only receive analog signals, not digital signals.)

Power Adapter: DC 12V 3-5A

Screen interface: LVDS Single 6

Screen voltage: 3.3V / 5V / 12V (Jump cap)

Not only USB interface can be used to upgrade programs, but also can use to play video/music/photo, basically, formats are supported. You can also set a boot display pictures or LOGO and Mirror Enable.

How to know the lvds cable type?

Step 1: Find your LCD model's resolution (you can check the resolution from this link: http://www.panelook.com/index.php)

Step 2: Find and write in the corresponding firmware.

Programming:

1. Put the firmware in formatted USB flash disk(FAT32), then insert the USB disk and the 7KEY-Button to the board

2. After turn on the power, the light of the 7key button be Red then flash red faster.

IT KEEPS flashing and NEVER STOP. it's normal, just wait about 1 minute, it means upgrade has finished. then power off and pull off the u-disk. (Note that write programs do not power outages, crashing won't be able to use)

Package included:

1 x Controller Board

1 x English Remote control

1 x IR

1 x 7key button

1 x 1ch 6bit 40Pins lvds cable 250mm length

2 x 4ohm 3W Speaker

1 x EU 12V 4A Power Adapter

Q&A:

Q1: T.SK105A.03 chip, 1280*800 resolution, after installing the firmware, the screen flickers

A2: Download this software and re-upgrade. If your 105 chip is unable to be upgraded, you can change the upgrade name to "UTS6710_sos" to force the upgrade. >>>https://www.renhotecic.com/image/download/rar/20210202043110UTS6710.rar<<<

Q2: Does eDP connector work with this item?

A2: The eDP interface is not directly compatible. There are two solution:

1): Use this product and purchase an eDP conversion board separately.
2): Buy the EDP driver board directly.

Q3: The remote control can not work?

A3: You must first burn the software to use the remote control.
