RGB 800mW White Laser Module Combined Red Green Blue 638nm 520nm 450nm TTL Driver Modulation
- Stock: In Stock
- Model: EB0017429
- SKU: EB0017429
| Specification | |
| Model | W800 |
| Wavelength | R: 638nm, G: 520nm, B: 450nm |
| Output Power | R: 180mW, G: 100mW, B: 520mW |
| Combined Optical Power Output | 800mW |
| Spot Mode | Round Spot |
| Divergence: | ≤1mrad |
| Laser Grade | Class 3 |
| Modulation Mode | TTL Modulation / Analog Modulation |
| Enter Stability | ±5% |
| Input Voltage | DC 12V |
| Rated Power Consumption | 11W |
| Operating Temperature: | -10~40℃ |
| Wire Length | 250mm |
| External Heat Dissipation | None |
| Operating Lifetime | 10000h |
| Product Size | Approx. 63x50x40mm |
| Product Weight | 200g |
Features:
1 x RGB 800mW White Laser Module
