GPS Receiver BS-708 USB GPS Receiver Module Antenna Laptop Replace BU-353S4 BU353S4
- Stock: In Stock
- Model: EB000457
- Dimensions: 0.00mm x 0.00mm x 18.00mm
- SKU: EB000457
support system: Mac-os,linux,Windows ME/98/CE,server 2003,server 2008,vista,xp,windows 7,windows 8,Windows 10,all windows series system.
The USB Driver for Windows Download:
https://www.renhotecic.com/image/download/zip/UBX-GNSS-CDC-ACM-windows_Driver_(UBX-drv-v1.2.0.8).exe.zip
NOTE: Please copy the URL to Internet Explorer, then download from the Internet Explorer.
| Parameter | Description | |
| Chip characteristics | Chip | U-blox U7 |
| Receiving mode | GPS, QZSS, WAAS, SBAS, EGNOS, MSAS | |
| Frequency | GPSL1, SBAS L1 | |
| Channel | 56 search channels | |
| Sensitivity | Track | -162dBm |
| Recapture | -160dBm | |
| Cold start | -148dBm | |
| Precision | Horizontal accuracy | 2.0 m CEP 2D RMS SBAS assist (open space) |
| Speed accuracy | 0.1m/s 95% (SA off) | |
| Time accuracy | 1us | |
| Start Time | Cold start | 29s |
| Warm start | 25s | |
| Hot Start | 1s | |
| Output Data | Baud rate | 4800bps-921600bps,default 9600bps |
| Output level | USB, TTL or RS232, default USB level | |
| Output protocol | Default NMEA-0183 protocol | |
| Standard GNSS | 1Hz-10Hz, default 1Hz | |
| Work limit | Height | 50,000m maximum |
| Speed | 515m/s maximum | |
| Gravity acceleration | 4g maximum | |
| Power consumption | Renhotec | DC 3.6V-5.5V, typical: 5.0V |
| Current | Normal 65mA@5.0V | |
| Physical parameter | Size | Diameter 56*height 18mm |
| Weight | 100 grams | |
| Line length | 2m | |
| Connector | USB 2.0 male | |
| Surroundings | Operating temperature | 40 °C ~ +85 °C |
| storage temperature | 40°C ~ +85°C | |
Output protocol sample:
$GPRMC,072500.00,A,2237.56075,N,11401.59641,E,1.502,343.54,020916,,,A*6E
$GPVTG,343.54,T,,M,1.502,N,2.782,K,A*31
$GPGGA,072500.00,2237.56075,N,11401.59641,E,1,07,1.09,109.0,M,-2.5,M,,*4E
$GPGSA,A,3,05,06,09,19,02,17,13,,,,,,2.07,1.09,1.76*0B
$GPGSV,2,1,08,02,45,336,45,05,51,250,43,06,43,037,39,09,23,056,41*76
$GPGSV,2,2,08,12,,,39,13,11,186,40,17,38,129,41,19,59,114,47*40
$GPGLL,2237.56075,N,11401.59641,E,072500.00,A,A*66
1 x BS-708 USB GPS Receiver Module
