ACS714 5A 5V Current Sensor Breakout Board Isolate Filter Resistance Capacitor Hall Effect Module

Based on 0 reviews. - Write a review

$11.99

Ex Tax: $11.99

Stock: In Stock
Model: EB0043373
SKU: EB0043373

Qty

Add to Cart

Buy Now Ask Question

Add to Wish List Compare this Product

Introduction:

This current sensor is a carrier board or breakout board for Allegro’s ACS715LLCTR-30A-T Hall effect-based linear current sensor, The sensor operates at 5 V and has an output sensitivity of 133 mV/A. The board ships fully populated with its SMD components.

Feature:

Designed for unidirectional input current from 0 to 5 A, but the sensor will provide meaningful feedback for currents as low as -1.5 A, and the robust IC can survive up to five times the overcurrent condition.

Conductive path internal resistance is typically 1.2 mΩ, and the PCB is made with 2-oz copper, so very little power is lost in the board.

Use of a Hall effect sensor means the IC is able to electrically isolate the current path from the sensor’s electronics (up to 2.1 kV RMS), which allows the sensor to be inserted anywhere along the current path and to be used in applications that require electrical isolation.

80 kHz bandwidth that can optionally be decreased by adding a capacitor across the board pins marked “filter”.

High accuracy and reliability: typical total output error of ±1.5% at room temperature with factory calibration, an extremely stable output offset voltage, and almost zero magnetic hysteresis.

Automotive-grade operating temperature range of -40°C to 150°C.

Package included:

1 x ACS714 5V 5A current sensor
