5pcs ZP01-MP503 Air-Quality Monitoring Module Formaldehyde Benzene Carbon Monoxide Hydrogen Alcohol Ammonia Smoke Essence for Air Cleaner Air Quality Monitor

5pcs ZP01-MP503 Air-Quality Monitoring Module Formaldehyde Benzene Carbon Monoxide Hydrogen Alcohol Ammonia Smoke Essence for Air Cleaner Air Quality Monitor
5pcs ZP01-MP503 Air-Quality Monitoring Module Formaldehyde Benzene Carbon Monoxide Hydrogen Alcohol Ammonia Smoke Essence for Air Cleaner Air Quality Monitor
5pcs ZP01-MP503 Air-Quality Monitoring Module Formaldehyde Benzene Carbon Monoxide Hydrogen Alcohol Ammonia Smoke Essence for Air Cleaner Air Quality Monitor
5pcs ZP01-MP503 Air-Quality Monitoring Module Formaldehyde Benzene Carbon Monoxide Hydrogen Alcohol Ammonia Smoke Essence for Air Cleaner Air Quality Monitor
5pcs ZP01-MP503 Air-Quality Monitoring Module Formaldehyde Benzene Carbon Monoxide Hydrogen Alcohol Ammonia Smoke Essence for Air Cleaner Air Quality Monitor
5pcs ZP01-MP503 Air-Quality Monitoring Module Formaldehyde Benzene Carbon Monoxide Hydrogen Alcohol Ammonia Smoke Essence for Air Cleaner Air Quality Monitor
5pcs ZP01-MP503 Air-Quality Monitoring Module Formaldehyde Benzene Carbon Monoxide Hydrogen Alcohol Ammonia Smoke Essence for Air Cleaner Air Quality Monitor
5pcs ZP01-MP503 Air-Quality Monitoring Module Formaldehyde Benzene Carbon Monoxide Hydrogen Alcohol Ammonia Smoke Essence for Air Cleaner Air Quality Monitor
5pcs ZP01-MP503 Air-Quality Monitoring Module Formaldehyde Benzene Carbon Monoxide Hydrogen Alcohol Ammonia Smoke Essence for Air Cleaner Air Quality Monitor
$17.99
Ex Tax: $17.99
  • Stock: In Stock
  • Model: EB0046111
  • SKU: EB0046111

Principle Introduction:

ZP01-MP503 air-quality module adopts flat surface semiconductor gas sensor. The module has very high sensitivity to volatile organic gases such as formaldehyde, benzene, carbon monoxide, ammonia, hydrogen, alcohol and smoke, essence &etc. The module has been aging, debugged, adjusted and calibrated. So it has good consistency and high sensitivity.

Applications :

Air cleaner, fresh-air system, intelligent integrated ceiling, air quality monitor, ventilator, air-condition.

Technical Parameters :

SensorAir quality sensor
Target Gasformaldehyde, benzene, carbon monoxide, hydrogen,alcohol, ammonia, smoke , essence &etc.
Physical InterfaceXH2.54-4P terminal sockets
Output Data0-3 grade pollution signal
Working Voltage5.0±0.2V DC (No voltage reverse connect protection)
Output DataTTL level (200ohm protected resistance inside)
Working Current≤60mA
Warm Up Time≤3 min
Response Time≤20s
RecoveryTime≤60s
OperatingTemperature0~50℃
OperatingHumidity≤95%RH
StorageTemperature-20~60℃
Storage Humidity≤60%RH
Size24×20×15mm(L×W×H)
Weight≤ 20g
Sensitivity Attenuator≤1%/year

Package Inlcuded:

5 x ZP01-MP503 Air-Quality Monitoring Module
