3pcs AD8302 Wideband Amplitude Phase Detection Impedance Analysis Module Amplifier Filter Mixer Loss and Phase Measurement
- Stock: In Stock
- Model: EB0043996
- SKU: EB0043996
Single chip silicon bipolar device, amplitude / phase measurement
Support cable:
BNC male to SMA male
| Frequency Hz | Signal source RMS@50 ohm | Source phase (degrees) | Output voltage V | |||
| CH1 | CH2 | CH1 | CH2 | VM | VP | |
| 500K | 0.2V | 0.2V | 0 | 90 | 0.908V | 0.907V |
| 500K | 0.1V | 0.2V | 0 | 90 | 0.724V | 0.906V |
| 500K | 0.2V | 0.1V | 0 | 90 | 1.093V | 0.908V |
| 500K | 0.2V | 0.2V | 0 | 180 | 0.908V | 0.032V |
| 500K | 0.2V | 0.1V | 0 | 180 | 1.094V | 0.023V |
| 500K | 0.1V | 0.2V | 0 | 180 | 0.725V | 0.022V |
| 500K | 0.2V / | 0.2V | 0 | -90 | 0.908V | 0.915V |
| 500K | 0.1V | 0.2V | 0 | -90 | 0.725V | 0.914V |
| 500K | 0.2V / | 0.1V | 0 | -90 | 1.093V | 0.915V |
| 500K | 0.2V | 0.2V | 0 | -180 | 0.909V | 0.032V |
| 500K | 0.2V / | 0.1V | 0 | -180 | 1.093V | 0.022V |
| 500K | 0.1V | 0.2V | 0 | -180 | 0.724V | 0.021V |
Package includes:
3 x AD8302 module
